Description Microtest 6363 LCR Meter The Microtest 6363 is a 10Hz to 20kHz Bench LCR Meter. Microtest a leader in electronic product design, produce LCR Meters and Impedance Analysers (Z), offering a wide range of test frequencies to suit multiple applications in the testing of electronic components. The Microtest 6363 bench LCR meter encompasses high accuracy with speed. The test frequency range is continuously adjustable from 10Hz to 20kHz with a high measurement accuracy of ±0.05% allowing four parameters to be tested simultaneously. Support for USB Host,RS-232, GPIB, Handler and LAN interfaces. Optional PC software for graphic analysing is also available Typical test environments include:- production line, quality assurance or incoming quality control or automated testing departments. Features: Test Frequency 10Hz – 20kHz Basic accuracy up to ±0.05% Low frequency 6565A(0.1Hz~200kHz) can measure aluminium electrolytic capacitors Synchronous test with four parameters settings List mode function up to 8 sets USB Host can storage testing screen and data Supports RS232, GPIB, Handler, LAN and USB Host interfaces Using in production line, quality assurance or incoming quality control or automated testing department PC Connection data analysis software is available Microtest 636* LCR Meter Comparison Table MODEL Test Frequency Basic Accuracy AC Drive Level DC Drive Level Output Impedance Measurement Circuit 6363 10Hz – 20kHz ± 0.05% 10mV to 2Vrms (1m Vrms resolution) 10mV to 2Vrms (1m Vrms resolution) 100Ω Series/Parallel 6364 10Hz – 100kHz ± 0.05% 10mV to 2Vrms (1m Vrms resolution) 10mV to 2Vrms (1m Vrms resolution) 100Ω Series/Parallel 6365 10Hz – 200kHz ± 0.05% 10mV to 2Vrms (1m Vrms resolution) 10mV to 2Vrms (1m Vrms resolution) 100Ω Series/Parallel 6366 10Hz – 500kHz ± 0.05% 10mV to 2Vrms (1m Vrms resolution) 10mV to 2Vrms (1m Vrms resolution) 100Ω Series/Parallel 6367 10Hz – 1MHz ± 0.05% 10mV to 2Vrms (1m Vrms resolution) 10mV to 2Vrms (1m Vrms resolution) 100Ω Series/Parallel Product Images Multi-Step Test Mode Learn more... Measuring Inductance Learn more... Measuring Capacitance Learn more... Four Parameters Displayed Learn more... USB Storage Testing Screen and Data Learn more... PC Link Software Sweeping Analysis (Option) Learn more...
