Description Renatl Rigol DSG815 Signal Generator The DSG815 RF Signal Generator has a Frequency Range of 9kHz to 1.5GHz. The DSG800 offers outstanding performance at an affordable price. There are two models available that cover output frequencies from 9kHz to 1.5GHz (DSG815) or 9kHz to 3GHz (DSG830). Maximum output power is 20dBm (typical). Phase noise reaches -105dBc/Hz (typical). The DSG800 also provides frequency and level sweep functions, AM/FM/ØM analogue modulations as well as a powerful pulse modulation function. With all of these features, the DSG800 is an excellent source for high quality signals (including RF, LF, sweep, pulse and a variety of analogue modulated signals) and for use as a stable reference. Compared to similar products, the DSG800 is cost effective, lightweight and occupies very little bench space. It’s the perfect choice for various fields such as education laboratories, industrial production lines, as well as research and development labs. Features: Maximum frequency 1.5GHz Maximum output level 20dBm Excellent value for money AM/FM/PM analogue modulation functions Pulse modulation function (optional) Versatile amplitude and frequency sweep functions USB host/device & LAN(LXI) Electronic attenuator – Avoids wear Internal protection functions Digital ALC Compact, light weight and easy to use Supplied with… USB cable, UK & European mains leads, quick guide Options include… Pulse modulator / pulse generator. pulse train generator, high stability reference oscillator, rack mount kit (for one instrument), rack mount kit (for two instruments), RCL standard calibration, RCL UKAS calibration Rigol DSG800 RF Signal Generator Comparison Table Model Maximum Frequency Amplitude Accuracy Phase Noise IQ Modulation Connectivity DSG815 1.5GHz <0.5dB <-112dBc/Hz No USB Host & Device, LAN (LXI) DSG821 2.1GHz <0.5dB <-112dBc/Hz No USB Host & Device, LAN (LXI) DSG821A 2.1GHz <0.5dB <-112dBc/Hz Yes USB Host & Device, LAN (LXI) DSG830 3GHz <0.5dB <-112dBc/Hz No USB Host & Device, LAN (LXI) DSG836 3.6GHz <0.5dB <-112dBc/Hz No USB Host & Device, LAN (LXI) DSG836A 3.6GHz <0.5dB <-112dBc/Hz Yes USB Host & Device, LAN (LXI) Product Images Complete AMFMØM Analogue Modulation Learn more... Amplitude Stability Learn more... Wide Range of High Power Output Learn more... Pulse Modulation Learn more... Low Phase Noise Learn more... High Amplitude Accuracy Learn more... Product Videos
